Kinugawa Turbo Super Core TD04-15T for Mitsubishi 6G72T 3000GT Dodge Stealth
APPLICATION
Designed as a direct-fit twin-turbo Super Core replacement for the Mitsubishi 6G72T 3.0L V6 Twin Turbo engine found in the Mitsubishi 3000GT VR4 and Dodge Stealth R/T Twin Turbo. Bolts directly onto the stock exhaust manifold and dump pipe without modification. The universal-type compressor housing inlet and outlet hoses/pipes require adaptation to fit your specific intercooler piping.
Maximum power figures are calculated from the compressor map choke flow (total turbo capability) and represent potential flywheel power. Actual performance depends on vehicle modifications, fueling, and tuning/calibration.
TURBO SPECIFICATION — TD04-15T
- Compressor wheel: 42.0 mm inducer / 56.0 mm exducer
- Compressor blade options: Cast 6+6 (optimized for low-end torque and spool) or Billet 6+6 / Billet 11+0 (optimized for top-end power and flow)
- Turbine wheel: 40.0 mm inducer / 47.1 mm exducer — Inconel 713 alloy
- Turbine blade options: STD (Standard) or STS (Superior Turbine Strike — ceramic dual ball bearing technology for faster response)
Learn more about STS technology →
COMPRESSOR HOUSING
- Type: Universal
- Inlet: 2.4" (60.9 mm)
- Outlet: 2.0" (50.8 mm)
COOLING & BEARING SYSTEM
- Cooling: Oil and water cooling (dual-circuit)
- Bearing: Journal bearing system
ACTUATOR / WASTEGATE SETTING
- Default: 1.0 bar (14.7 psi)
- Custom settings available on request: 0.3 / 0.5 / 0.8 / 1.2 / 1.5 / 1.7 / 2.0 bar — add a note at checkout or contact us before ordering.
BALANCING & QUALITY
- Brand new CHRA, precision-balanced on a SCHENCK MBRS 110 (Germany) balancing machine
- Each unit ships with an individual balance report and anti-counterfeit authentication tag
KIT INCLUDES
- 2 × Kinugawa TD04-15T Super Core CHRA (front and rear turbo)
- 2 × Balance reports with anti-counterfeit tags
MANUFACTURER
- Kinugawa Turbo Systems — Made in Taiwan
WARRANTY
- No warranty
